29+
| SIZE | M | L | XL |
|---|---|---|---|
| Reach | 408.0 | 420.5 | 433.0 |
| Stack | 609.5 | 633.0 | 656.5 |
| Head Tube Angle | 70.0° | 70.0° | 70.0° |
| Head Tube Length | 100.0 | 125.0 | 150.0 |
| Seat Tube Length | 457.2 | 507.9 | 558.7 |
| BB Drop | 80.0 | 80.0 | 80.0 |
| Wheelbase | 1090.0 | 1111.0 | 1132.5 |
| Chainstay Length | 451.0 | 451.0 | 451.0 |
| Top Tube Length, Actual | 560.5 | 580.0 | 600.0 |
| Top Tube Length, Effective | 600.0 | 620.0 | 640.0 |
| Seat Tube Angle | 72.5° | 72.5° | 72.5° |
| Standover Height | 805.0 | 840.0 | 875.0 |
| Stem Length | 70 | 70 | 80 |
| Stem Angle | 6° | 6° | 6° |
| Handlebar Width | 735 | 735 | 735 |
| Crank Length | 175 | 175 | 175 |
| Fork Length | 468.0 | 468.0 | 468.0 |
| Fork Rake | 43.0 | 43.0 | 43.0 |
27.5+
| SIZE | XS | S | M |
|---|---|---|---|
| Reach | 385.0 | 398.0 | 410.5 |
| Stack | 556.0 | 579.5 | 603.0 |
| Head Tube Angle | 69.0° | 69.0° | 69.0° |
| Head Tube Length | 90.0 | 115.0 | 140.0 |
| Seat Tube Length | 346.4 | 406.4 | 457.2 |
| BB Drop | 60.0 | 60.0 | 60.0 |
| Wheelbase | 1052.3 | 1074.0 | 1096.0 |
| Chainstay Length | 435.0 | 435.0 | 435.0 |
| Top Tube Length, Actual | 536.3 | 547.0 | 563.1 |
| Top Tube Length, Effective | 555.0 | 575.0 | 595.0 |
| Seat Tube Angle | 73.0° | 73.0° | 73.0° |
| Standover Height | 726.0 | 766.0 | 802.0 |
| Stem Length | 60 | 60 | 70 |
| Stem Angle | 6° | 6° | 6° |
| Handlebar Width | 685 | 685 | 735 |
| Crank Length | 170 | 170 | 175 |
