700c
| 56cm | 58cm | 60cm | 62cm | 64cm | |
|---|---|---|---|---|---|
| Reach | 389.3 | 394.4 | 403.0 | 401.0 | 406.1 |
| Stack | 588.0 | 606.1 | 623.2 | 643.2 | 658.4 |
| Head Tube Angle | 72.0° | 72.0° | 72.0° | 72.0° | 72.0° |
| Head Tube Length | 152.0 | 171.0 | 189.0 | 210.0 | 226.0 |
| Seat Tube Length | 560.0 | 580.0 | 600.0 | 620.0 | 640.0 |
| BB Drop | 78.0 | 78.0 | 78.0 | 78.0 | 78.0 |
| Wheelbase | 1055.6 | 1066.7 | 1080.8 | 1085.3 | 1095.3 |
| Chainstay Length | 460.0 | 460.0 | 460.0 | 460.0 | 460.0 |
| Top Tube Length, Actual | 564.5 | 580.2 | 594.8 | 603.9 | 615.0 |
| Top Tube Length, Effective | 570.0 | 586.0 | 600.0 | 610.0 | 620.0 |
| Seat Tube Angle | 73.0° | 72.5° | 72.5° | 72.0° | 72.0° |
| Standover Height | 811.9 | 829.8 | 847.8 | 866.5 | 883.6 |
| Stem Length | 100 | 110 | 120 | 120 | 120 |
| Stem Angle | 6° | 6° | 6° | 6° | 6° |
| Handlebar Width | 440 | 440 | 460 | 460 | 460 |
| Crank Length | 175 | 175 | 175 | 175 | 175 |
| Fork Length | 390.0 | 390.0 | 390.0 | 390.0 | 390.0 |
| Fork Rake | 45.0 | 45.0 | 45.0 | 45.0 | 45.0 |
