Description

2017 Model

SIZE	XS	S	M	L	XL (Frameset Only)
Reach	371	393	415	431	446
Stack	551	561	570	585	604
Head Tube Angle	71.0°	71.0°	71.0°	71.0°	71.0°
Head Tube Length	125	135	145	160	180
Seat Tube Length	336	406	457	508	559
BB Drop	40	40	40	40	40
Wheelbase	1016	1041	1066	1086	1108
Chainstay Length	425	425	425	425	425
Top Tube Length, Actual	530.6	546.7	568.1	589.0	608.6
Top Tube Length, Effective	545	570	595	615	630
Seat Tube Angle	73.0°	73.0°	73.0°	73.0°	73.0°
Standover Height	720	749	778	809	843.0
Stem Length	90	90	100	110
Stem Angle	7°	7°	7°	7°
Handlebar Width	685	685	735	735
Crank Length	170	170	175	175

2014 Model

SIZE	xSmall (14)	Small (16)	Medium (18)	Large (20)	xLarge (22)
Reach	376.5	398.6	420.8	436.4	445.6
Stack	551.0	560.5	569.9	584.1	603.0
Head Tube Angle	71.0°	71.0°	71.0°	71.0°	71.0°
Head Tube Length	90.0	100.0	110.0	125.0	145.0
Seat Tube Length	355.6	406.4	457.5	508.8	558.8
BB Drop	40.0	40.0	40.0	40.0	40.0
Wheelbase	1011.9	1037.3	1062.6	1083.2	1098.8
Chainstay Length	419.0	419.0	419.0	419.0	419.0
Top Tube Length, Actual	532.0	549.0	570.0	590.0	608.3
Top Tube Length, Effective	546.0	571.0	596.0	616.0	631.0
Seat Tube Angle	73.0°	73.0°	73.0°	73.0°	73.0°
Standover Height	717.0	745.0	774.0	804.0	838.0
Fork Length	453.0	453.0	453.0	453.0	453.0
Fork Rake	40.0	40.0	40.0	40.0	40.0
